Key Features

Operating temperature range :    -25 °c to +85°c
Operating frequency range :    40 Hz to 60 Hz
Capacitance range (@100 Hz & 250c) :     20 Mfd to 1350 Mfd 410%)
4 Voltage range :     400v ac to 440v ac
Surge voltage :     528v ac for 440v ac rate capacitor
Power factor/ Tangent of loss angle (440v ac,50 Hz&250c)  :      10% Maximum
Insulation voltage   :    It can withstand 3 KV AC for 2 sec. between termination and outer case
Insulation resistance:      Minimum 100 MO between leads and the case
Polarity :    May be connected either way
